5.5 Trigger multiple pipelines

Orchestrating multiple pipelines is a common requirement in production data environments where complex workflows span multiple interdependent processes. Mage provides several approaches for coordinating pipeline execution across different triggers and schedules.

Orchestration blocks in Mage Pro

What are orchestration blocks: Orchestration blocks are specialized components in Mage Pro that enable coordination and management of multiple pipeline executions. These blocks provide declarative control over complex workflows, allowing you to define dependencies, execution order, and conditional logic for multi-pipeline scenarios.

Basic orchestration block structure:

from mage_ai.orchestration.triggers.api import trigger_pipeline
if 'data_exporter' not in globals():
    from mage_ai.data_preparation.decorators import data_exporter

@data_exporter
def trigger(*args, **kwargs):
    """
    Trigger another Mage pipeline to run.
    """
    trigger_pipeline(
        'pipeline_uuid',        # Required: enter the UUID of the pipeline to trigger
        variables={},           # Optional: runtime variables for the pipeline
        check_status=False,     # Optional: poll and check the status of the triggered pipeline
        error_on_failure=False, # Optional: if triggered pipeline fails, raise an exception
        poll_interval=60,       # Optional: check the status of triggered pipeline every N seconds
        poll_timeout=None,      # Optional: raise an exception after N seconds
        verbose=True,           # Optional: print status of triggered pipeline run
    )

Key orchestration parameters:

• pipeline_uuid: The unique identifier of the target pipeline to trigger

• variables: Runtime variables passed to the triggered pipeline

• check_status: Enable polling to monitor the triggered pipeline's execution status

• error_on_failure: Control whether upstream pipeline failures should stop the orchestration

• poll_interval: Frequency of status checks when monitoring enabled

• poll_timeout: Maximum time to wait for pipeline completion before timing out

• verbose: Enable detailed logging of triggered pipeline execution

Pipeline dependencies and sequencing

Sequential pipeline execution: When pipelines must execute in a specific order, you can coordinate them through several methods:

Method 1: Staggered schedule triggers Configure schedule triggers with time offsets to ensure proper sequencing:

Pipeline A (data_extraction): Daily at 2:00 AM
Pipeline B (data_transformation): Daily at 3:30 AM
Pipeline C (reporting)

Method 2: API trigger chaining

Use callback blocks or data exporters to trigger downstream pipelines via API calls:

# In Pipeline A's callback block
@callback
def trigger_downstream_pipeline(data, **kwargs):
    import requests

    # Trigger Pipeline B after Pipeline A completes
    response = requests.post(
        '<https://your-mage-instance.com/api/pipeline_schedules/pipeline_b_trigger/pipeline_runs>',
        headers={'Authorization': 'Bearer your_token'},
        json={'pipeline_run': {'variables': {'upstream_run_id': kwargs.get('pipeline_run_id')}}}
    )

Method 3: sensor-based coordination Use sensor blocks to monitor completion status and trigger dependent pipelines:

# Sensor block monitoring for upstream completion
@sensor
def check_upstream_completion(**kwargs):
    # Check if Pipeline A completed successfully
    upstream_status = check_pipeline_status('pipeline_a_run_id')
    return upstream_status == 'completed'

Common orchestration patterns

Sequential pipeline execution: When pipelines must execute in a specific order, orchestration blocks can coordinate them through dependency management:

Fan-out pattern: One upstream pipeline triggers multiple downstream pipelines in parallel:

Fan-In pattern:

Multiple upstream pipelines feed into a single downstream pipeline:

Diamond Pattern:

Combines fan-out and fan-in for complex data workflows:

Best practices for multi-pipeline orchestration

Error Handling and Recovery:

• Implement proper error handling across orchestrated pipelines

• Use appropriate timeout settings for dependent pipelines

• Consider retry mechanisms for transient failures

• Monitor pipeline dependencies through logging and alerts

Resource Management:

• Stagger execution times to avoid resource conflicts

• Monitor system resources during peak orchestration periods

• Use appropriate timeout settings for each pipeline stage

• Consider using different compute resources for resource-intensive pipelines

Monitoring and Observability:

• Implement comprehensive logging across all orchestrated pipelines

• Set up alerts for pipeline failures that could break downstream dependencies

• Track end-to-end execution times for the complete workflow

• Maintain visibility into data lineage across pipeline boundaries

Multi-pipeline orchestration enables complex data workflows while maintaining modularity and reusability of individual pipeline components.
